Papa-Alpha PA-31 Rudder Trim Rigging ToolClick image to enlarge
01
Papa-Alpha PA-31 Rudder Trim Rigging Tool
Pilot Shop · Papa-Alpha Tools · RWAS

From the workbench

Papa-Alpha PA-31 Rudder Trim Rigging Tool

Applicability guide for the Papa-Alpha PA-31 rudder trim rigging tool set. Match the aircraft model and serial-number range before ordering; serial ranges marked N/A do not use this rudder trim tool.

By the RWAS Pilot Shop Desk◆From RWAS
Price
$349.99
Available to order
Airframe: PA-31 Rudder Trim Rigging Tool #1 - SKU RT-01
Application chart

PA-31 rudder trim tool applicability

Use the aircraft model and serial-number range together. The chart below separates the PA-31 Rudder Trim Rigging Tool #1, the PA-31P Rudder Trim Rigging Tool #2, and serial ranges where this rudder trim tool is not applicable.

11Tool #1 ranges
2Tool #2 ranges
6Not applicable
ModelSerial numberRudder trim rigging tool
PA-31-30031-228 thru 31-511N/A
PA-31-31031-5 thru 31-900N/A
PA-31-31031-7300901 thru 31-7512072N/A
PA-31-32531-7512006 thru 31-8312019, and 31-7400990N/A
PA-31-350 Navajo Chieftain31-5001, 31-5002, 31-5003N/A
PA-31-350 Navajo Chieftain31-7305005 thru 31-8452021N/A
PA-31-350 T102031-8253001 thru 31-8453021PA-31 Rudder Trim Rigging Tool #1
PA-31P31P-3 thru 31P-80PA-31P Rudder Trim Rigging Tool #2
PA-31P31P-7300110 thru 31P-7730012PA-31P Rudder Trim Rigging Tool #2
PA-31P-350 Mojave31P-8414001 thru 31P-8414050PA-31 Rudder Trim Rigging Tool #1
PA-31T Cheyenne31T-7400002 thru 31T-7720069PA-31 Rudder Trim Rigging Tool #1
PA-31T Cheyenne II31T-7820001 thru 31T-8120104PA-31 Rudder Trim Rigging Tool #1
PA-31T1 Cheyenne I31T-7804002 thru 31T-8104101PA-31 Rudder Trim Rigging Tool #1
PA-31T1 Cheyenne IA31T-8304002 thru 31T-1104017PA-31 Rudder Trim Rigging Tool #1
PA-31T2 Cheyenne II XL31T-8166002 thru 31T-1166008PA-31 Rudder Trim Rigging Tool #1
PA-31T3 T104031T-5575001PA-31 Rudder Trim Rigging Tool #1
PA-31T3 T104031T-8275001 thru 31T-8275017, 31T-8275025PA-31 Rudder Trim Rigging Tool #1
PA-31T3 T104031T-8375001 thru 31T-8375003, 31T-8375005PA-31 Rudder Trim Rigging Tool #1
PA-31T3 T104031T-8475001PA-31 Rudder Trim Rigging Tool #1
Order & fulfillmentBased on inventory, Papa-Alpha parts can be shipped same day if ordered before 2pm local.
Warranty & serviceManufacturer warranty. Service and support from our Part 145 repair station at KYKN in Yankton.
Talk to a pilotCall (605) 299-8178 — staffed by pilots and A&Ps, not a call center.
